Product Details:
Payment & Shipping Terms:
|
| Pitch: | 10mm | Led Type: | SMD |
|---|---|---|---|
| Cabinet Size: | 960x960 | Brightness: | 6500nits |
| IP Rate: | IP65 | Refresh Rate: | 3840 Hz |
| Highlight: | P10 Stadium Sports Perimeter LED Display,High Refresh Rate Sports Perimeter LED,10mm Sports Perimeter LED Display |
||
P10 Stadium Sports Perimeter High Refresh Rate LED Display
Main features of P10 indoor perimeter LED display basketball stadium advertising display
1. Claw lock system to link cabinets to avoid visible gaps between cabinets;
2. Soft rubber mask facia to protect the screen and the players on impact;
3. Aliminum cabinets with light weight;
4. Synchronous and asynchronous control systems together, the most stable performance;
5. Simple power and data connections, daisy chain from one cabinet to the next for fast connection;
6. Any cabinet in any position, no need for numbering cabinets and ensuring they are connected in the correct order;
7. Easy software set-up when cabinets are connected;
8. Wide viewing angle, 140 degrees both horizontal and vertical;
9. Customizable for various sizes;
10. Excellent after-sales service, warranty of three years;
11. CE, RoHS, ISO certificate
| Parameter | Unit | Value |
| Pitch | mm | 6 |
| Brightness | nits | 6,500 |
| Color temperature | deg. K | 6,500 |
| Viewing angle – Horizontal (50% brightness) | deg. | 140(-70 ~ +70) |
| Viewing angle – Vertical (50% brightness) | deg. | 140(-70 ~ +70) |
| Panel weight | kg | 37 |
| Panel width | mm | 960 |
| Panel height | mm | 960 |
| Panel depth | mm | 134 |
| Panel area | sq. m. | |
| Panel material | Epoxy paint-coated aluminum | |
| Panel Mode | Quick Assembly Cabinet with Bracket | |
| Panel protection | Soft mask | |
| Ingress protection (front/rear) | IP | IP22/IP43 |
| Operating temperature range | deg. C | -30 to +60 |
| Humidity operating | RH | 10% ~ 90% |
| Pixel type and configuration | R/G/B | 3in1 SMD |
| Resolution per panel | 320×160 | |
| Dot per panel | 10000 | |
| Dot per sq. meter | 27,777 | |
| LED per sq. meter | 27,777 | |
| Recommended minimum viewing distance | m | 4.56 |
| Recommended best viewing distance | m | 10~60 |
| Colors | 281 Trillion | |
| Grey scale (linear) | Levels | 65,536 levels per color |
| Brightness control | Levels | 100 |
| Contrast ratio | 1,000:1 | |
| Processing depth | bit | 16 |
| Video frame rate | Hertz | 60 |
| Display refresh rate | Hertz | 180~3,000 |
| Input voltage (nominal) | VAC | 110 to 240 |
| Input power frequency | Hertz | 50 to 60 |
| Input power (max) | Watts/ cabinet. | 1,000 |
| Input power (typical) | Watts/ cabinet. | 400 |
| Lifetime (50% brightness) | Hours | ≥100,000 |
| Red wavelength (dominant) | nm | 620~625 |
| Green wavelength (dominant) | nm | 520~525 |
| Blue wavelength (dominant) | nm | 470~475 |
| Multimedia data format | DVI,MPG,AVI,WMV,RM etc. | |
| Data interconnection | UTP Cat 5/Optical Fiber | |
| Mounting system | Stand on ground by bracket |
FAQ:
Q1: The warranty of your LED dispaly ?
A: We offer 2-3 year warranty for our different led display screen series, 100,000 hours life span for the led lamps, and lifetime technology support with 7/24 phone answering service if you have any problem with our led screen.
Q2: Whats your payment term? How long it takes to delivery?
A: We normally accept T/T and L/C,and other payment options is negotiable for your convenience. A 30% deposit is needed in advance, and the rest 70% be paid before delivery. Our average lead time is 15 days.
Q3: What's the controlling system?
A: Our standard controlling system for this model is Novastar. Also support other controlling system such as Linsn, etc.
About Us
►Rich experience: established in 2005; familiar with technical and material about LED display.
►Absolute OEM service: providing the most suitable solution for you according to your different demands (such as quality, price and etc.). At least 3 different types in one material are provided for your choice , and with the lowest-cost custom service.
►Powerful R&D ability: excellent engineers are constantly developing new products and improving them.
►Good quality:All products have passed CE, ROHS, FCC certification.
►Thoughtful service: we always serve you heart and soul, striving to make our products meet your demands in maximum degree.
We guarantee all our LED products for 2 years and provide lifetime maintenance charging only for raw materials. We provide an excellent after-sale service, which contains free training, free CAD drawings, for more convenience and free consultation lifetime.
