Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 5mm | Panel Material: | Steel/Aluminum |
|---|---|---|---|
| Processing: | 16 Bit | Refresh Rate: | >1920 Hz |
| Brightness: | >5000 Nits | Servicing: | Front/Rear |
| Colors: | 281 Trillion | Contrast Ratio: | 2000:1 |
| Highlight: | Waterproof Outdoor Fixed LED Display,5000nits Curved Outdoor Fixed LED Display,5mm Pitch Outdoor Fixed LED Display |
||
P5mm Fixed LED Display Outdoor for Advertising
Specification of P5mm Fixed
| BOF-4 | BOF-6 | BOF-8 | BOF-10 | |
| Physical Pitch | 4.81 mm | 6.67 mm | 8 mm | 10 mm |
| Pixel Configuration | SMD 2727 | SMD 2727 | SMD 3535 | SMD 3535 |
| Pixel Density | 43,264 pixels/m² |
28,224 pixels/m² |
15,625 pixels/m² |
10,000 pixels/m² |
| Module Dimensions (W × H) (mm) | 250 × 250 | 320 × 320 | 256 × 256 | 320 × 160 |
| Panel Dimensions (mm) | 1000 × 1000 × 187 | 1280 × 960 × 187 | 1280 × 960 × 187 | 1280 × 960 × 187 |
| NO .of Modules Per Panel (W × H) | 4 × 4 | 4 × 3 | 5 × 3 | 3× 6 |
| Physical Resolution of Module (W × H) | 52 × 52 | 48 × 48 | 32 × 32 | 32 × 16 |
| Physical Resolution of Panel (W × H) | 208 × 208 | 192 × 144 | 160 × 96 | 96 × 96 |
| Panel Material | Steel / Aluminum | Steel / Aluminum | Steel / Aluminum | Steel / Aluminum |
| Weight | 65/45 | 65/45 | 65/45 | 65/45 |
| Processing | 16 bit | 16 bit | 16 bit | 16 bit |
| Colors | 281 trillion | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 2,000: 1 | 2,000: 1 | 2,000: 1 | 2,000: 1 |
| Average Power Consumption | 360 W/panel | 360 W/panel | 360 W/panel | 360 W/panel |
| Max Power Consumption | 900 W/panel | 900 W/panel | 900 W/panel | 900 W/panel |
| Refresh Rate | >1,920 Hz | >1,920 Hz | >1,920 Hz | >1,920 Hz |
| Brightness | ≥6500 nits | ≥6500 nits | ≥6500 nits | ≥6500 nits |
| Horizontal Viewing Angle | 160° | 160° | 160° | 160° |
| Vertical Viewing angle | 140° | 140° | 140° | 140° |
| Expected Lifetime | 100, 000 Hrs | 100, 000 Hrs | 100, 000 Hrs | 100, 000 Hrs |
| Servicing | Front / Rear | Front / Rear | Front / Rear | Front / Rear |
| IP Rating (Front/Rear) | IP 65/ IP 54 | IP 65/ IP 54 | IP 65/ IP 54 | IP 65/ IP 54 |
| Operating Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
| Storage Temp/Humidity | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% | -20ºC - 50ºC / 10% - 90% |
Features of Outdoor P5 Fixed LED Display.
Multifunctional Module Buckle
Special multifunctional module buckle designed for adjusting gaps between module and cabinet to ensure smoothness and alignment.
Fast Installation and Easy Maintenance
The fast lock system design guarantees a quick and easy installation
Front access
COMPANY INTRODUCTION
Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005, a world-class manufacturer of technologically advanced LED displays, is SHENZHEN BAKO LTD holding end professional customers among domestic and overseas markets.
Do not be hesitate to contact us if you have any quiry!
FAQ
Q1. Do you provide samples?is it free or extra?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q2.How to order?
A:Please send us your purchase order by Email or we can make you proforma invoice under your request.
We need to know the following information for your order before sending you PI.
1)Product information-Quantity,Specification(Size,Material,Technological if needed and Packing requirements etc.
2)Delivery time required.
3)Shipping information-Company name,Street address,Phone&Fax number,Destination sea port.
4)Forwarder's contact details if there's any in China.
Q3. Do you offer guarantee for the products?
A: Yes,we offer 2-5 years warranty to our products.
