| Physical Pitch: | 4mm, 6mm, 8mm, 10mm | Pixel Configuration: | SMD |
|---|---|---|---|
| Module Dimensions: | 192mm X 192mm, 320mm X 160mm | Panel Dimensions: | 960mm X 960mm |
| Panel Material: | Steel/ Aluminum | Brightness: | 6500nits |
| Refresh Rate: | 1920Hz | Expected Lifetime: | 1000,000Hrs |
| Servicing: | Rear | IP Rating: | IP65 |
| Scan Method: | 1/16 Scan | Weight: | 45kg |
| Highlight: | Steel Aluminum Outdoor Fixed LED Display,Outdoor Fixed LED Display 6500nits,SMD2727 Fixed Outdoor LED Billboard |
||
| BOF-4 | BOF-6 | BOF-8 | BOF-10 | |
| Physical Pitch | 4.81mm | 6.67mm | 8mm | 10mm |
| Pixel Configuration | SMD2727 | SMD2727 | SMD3535 | SMD3535 |
| Pixel Density | 43,264 pixels/sqm | 22,500 pixels/sqm | 15,625 pixels/sqm | 10,000 pixels/sqm |
| Module Dimension (W*H)(mm) | 250*250 | 320*320 | 256*256 | 320*320 |
| Panel Dimensions(mm) | 1000*1000*150 | 1280*960*150 | 1280*768*150 | 1280*960*150 |
| Physical Resolution of Module(W*H) | 52*52 | 48*48 | 32*32 | 32*32 |
| Physical Resolution of Panel(W*H) | 208*208 | 192*144 | 160*96 | 128*96 |
| Panel Material | Steel/Aluminum | Steel/Aluminum | Steel/Aluminum | Steel/Aluminum |
| Weight(kg/sqm) | 65/45 | 65/45 | 65/45 | 65/45 |
| Processing | 16 bit | 16 bit | 16 bit | 16 bit |
| Contrast Ratio | 2,000:1 | 2,000:1 | 2,000:1 | 2,000:1 |
| Average Power Consumption | 360W/panel | 360W/panel | 360W/panel | 360W/panel |
| Max Power Consumption | 900W/panel | 900W/panel | 900W/panel | 900W/panel |
| Brightness | >6,500nits | >6,500nits | >6,500nits | >6,500nits |
| Refresh Rate | >1,920Hz | >1,920Hz | >1,920Hz | >1,920Hz |
| Vertical Viewing Angle | 160° | 160° | 160° | 160° |
| Horizontal Viewing Angle | 140° | 140° | 140° | 140° |
| Servicing | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| IP Rating(Front/Rear) | IP65/IP54 | IP65/IP54 | IP65/IP54 | IP65/IP54 |
Advantages
* Competitive Price: Orders directly from the manufacturer to reduce intermediate expenditure, buy high-quality sign products with more reasonable price
* First-class Quality: We provide you with high-quality signs produced by our experienced technicians which use high quality raw materials
* Strict Leading Time: Depending on the type and quantity of ordered signs, we generally need only 4 to 15 days to complete the production
* OEM service offered, Customized service offered, Design service offered
* Competitive price, Short delivery, Timely transportation, Installation instruction
* Long time cooperate with signs company, construction company, design company, advertising company, chain shops, distributors, hotels, shopping malls and etc.
Tips
* Payment: We accept the L/C, T/T, Western Union.
* Shipment: We will ship within 30 working days after you placed the order, but the specific delivered time will be affected by the shipping company and shipping details.
* Package: We usually pack the product in a wooden box or flight case.
