Outdoor Fixed LED Display 6500nits SMD Seamless Splicing Front Service

Outdoor Fixed LED Display 6500nits SMD Seamless Splicing Front Service
Outdoor Fixed LED Display 6500nits SMD Seamless Splicing Front Service

Large Image :  Outdoor Fixed LED Display 6500nits SMD Seamless Splicing Front Service

Product Details:

Place of Origin: China
Brand Name: Bako Vision
Certification: CE RoHS
Model Number: BOF

Payment & Shipping Terms:

Minimum Order Quantity: 1 SQM
Price: negotiable price
Packaging Details: flight case/plywood case
Delivery Time: 25-35days
Payment Terms: L/C, T/T
Supply Ability: 6000 sqm/month
Contact Now
Detailed Product Description
Usage: Outdoor Pixel Pitch: 4.81mm
Pixel Density: 43264 Pixels/m2 Module Size: 250*250
Panel Size: 1000*1000 Module Resolution: 52*52
Cabinet Resolution: 208*208 Screen Size: Customized
Brightness: >6500nits IP Rating: IP65
Lifetime: 100000Hrs Warrantys: 2 Years
Servicing: Front Color: Full Color
Highlight:

IP21 Outdoor Fixed LED Display

,

6500nits SMD Outdoor Fixed LED Display

,

Seamless Splicing Outdoor Fixed LED Panel

Basic Info.

Model NO.
BOF
Pixel Density
15625 Pixels/M2
Scanning Mode
1/16 Scan
Display Type
LED Video Display
Application
Stage Performance
Certification
CE, RoHS, UL, CCC, ETL
Trademark
BAKO VISION
Transport Package
Wooden Case
Origin
China
HS Code
8528591090
Outdoor Fixed LED Display 6500nits SMD Seamless Splicing Front Service 0




















Specifications

  BOF-F-4 BOF-F-5 BOF-F-6 BOF-F-8
Physical Pitch 4.81 mm 5.95 mm 6.67 mm 8 mm
Pixel Configuration SMD 2727 SMD 2727 SMD 2727 SMD 3535
Pixel Density 43,264 pixels/m簡 28,246 pixels/m 22,500 pixels/m簡 15,625 pixels/m簡
NO.of Modules Per Panel (W × H) 250 × 250 250 × 250 320 × 320 320 × 160
Module Dimensions (W× H)(mm) 1000 × 1000 × 150 500 × 1000 × 150 1280 × 960 × 150 1280 × 960 × 150
Panel Dimensions (mm) 4 × 4 2 × 4 2 × 4 2 × 4
Physical Resolution of Module (W × H) 52 × 52 52 × 52 48 × 48 40 × 20
Physical Resolution of Panel (W × H) 208 × 208 84 × 168 192 × 144 160 × 120
Panel Material Steel / Aluminum Steel / Aluminum Steel / Aluminum Steel / Aluminum
Average Power Consumption 360 W/m² 360 W/m² 360 W/m² 360 W/m²
Max Power Consumption 900 W/m² 900 W/m² 900 W/m² 900 W/m²
Refresh Rate >1,920 Hz >1,920 Hz >1,920 Hz >1,920 Hz
Brightness >6,500 nits >6,500 nits >6,500 nits >6,500 nits
Expected Lifetime 100,000 Hrs 100,000 Hrs 100,000 Hrs 100,000 Hrs
Servicing Front Front Front Front
IP Rating (Front/Rear) IP65 IP65 IP65 IP65
Operating Temp/Humidity -20-50℃ / 10-90% -20-50℃ / 10-90% -20-50℃ / 10-90% -20-50℃ / 10-90%
Storage Temp/Humidity -20-50℃ / 10-90% -20-50℃ / 10-90% -20-50℃ / 10-90% -20-50℃ / 10-90%
Scan Method 1/13 Scan 1/7 Scan 1/10 Scan 1/4 Scan
Outdoor Fixed LED Display 6500nits SMD Seamless Splicing Front Service 1Outdoor Fixed LED Display 6500nits SMD Seamless Splicing Front Service 2


As a professional LED display manufacturer, BAKO VISION has developed from a small workshop to a professional LED display supplier. More than 100 countries has witnessed BAKO VISION's qualified LED displays and humanized service. Besides, BAKO VISION has participated in about 30 world famous activities.

Now BAKO VISION is equipped with eighteen automatic SMT lines and three DIP lines with high speed machines of famous brand such as Panasonic and Samsung. For one thing, this can ensure the quality of the SMT and DIP operation, for another, there is no need for clients to worry about delivery time. Clients can always get the goods on or ahead of time. Now our production capacity is eight hundred million dots per month. If we take P3.91 as an example, it is about twelve thousand square meters per month.

Quality is key important for a company. We have a full series of quality testing tools. After each process, there is QC for check. Before shipment, we make sure that there are 48 hours' ageing, which prevent any probable problem before package.

At present, BAKO VISION focuses on three series of products: outdoor SMD LED display such as P8, diamond series die-casting rental LED displays such as P3.91, indoor and outdoor small pitch LED display such as indoor P1.6 and outdoor P5. We are sure that cooperation between BAKO VISION and you will be an enjoyable journey.
