Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 4.81mm | Pixel Density: | 43264pixels/m2 |
|---|---|---|---|
| Cabinet Dimension: | 500x1000mm | Cabinet Material: | Die Casting Aluminum |
| Ingress Protection(front/rear): | IP65/IP54 | MTBF: | ≥1000hrs |
| Pixel Failure: | <0.0003 | ||
| Highlight: | P3.91 Outdoor Led Display,3840Hz Outdoor Led Display,3840Hz Stage Rental LED Display |
||
Refresh Rate 3840Hz P3.91 Outdoor Led Display With 50x100cm Panel
Refresh rate of 3840Hz P3.91 outdoor led display with 50x100cm panel
P4.81 Outdoor Stage Rental Led display features
1, High brightness uniformity and color uniformity(≥95%).
2, Super thin and light with aluminum cabinet design.
3, Good anti-UV and anti-oxidation performance.
4, Large viewing distance, 140° in horizontal, 140° in vertical.
5, Excellent flatness and no splicing gap between modules
6, Quick installation and removal with facile connection lock
P4.81 Outdoor Stage Rental Led display Specs
| BIR-II-4 | |
| Physical Pitch(mm) | 4.81 |
| Pixel Configuration | SMD2727 |
| Pixel Density | 43.264 pixels/sqm |
| Module Dimensions (W × H) (mm) | 250x250 |
| Panel Dimensions (mm) | 500x500x80/500x1000x80 |
| No. of Modules Per Panel (W × H) | 2x2/2x4 |
| Physical Resolution of Module (W x H) | 52x52 |
| Physical Resolution of Panel (W x H) | 104x104/104x208 |
| Panel Material | Die-casting Aluminum |
| Single Cabinet Weight | 8/14 kg / panel |
| Gray Scale | 16 bit |
| Colours | 281 trillion |
| Contrast Ratio | 4,000:1 |
| Average Power Consumption | 310W /m2 |
| Max Power Consumption | 750 W / ㎡ |
| Operating Temp/Humidity | -10°-60℃/10%-60% |
| Storage Temp/Humidity | -30°-60℃/10%-60% |
| Refresh Rate | >1,920 Hz |
| Brightness | ≥1,200nits |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing Angle | 140° |
| Expected Lifetime | 100,000 Hrs |
Panels of P4.81 outdoor 50x100cm
