| Pixel Pitch: | 2.97mm | Pixel Density: | 112,896pixels/m2 |
|---|---|---|---|
| Cabinet Dimension: | 500x1000mm | Cabinet Material: | Die Casting Aluminum |
| Ingress Protection(front/rear): | IP65/IP54 | MTBF: | ≥1000hrs |
| Pixel Failure: | <0.0003 | ||
| Highlight: | 50x100cm Led Video Panel,P2.97 Led Video Panel,P2.97 Led Panel Display |
||
Front Access P2.6 50x100cm Led Video Panel Display With 3840Hz Refresh Rate
Front access P2.6 50x100cm led video panel display with 3840Hz refresh rate
P2.97 Indoor Rental Led display Features
1, Front access module makes easy maintenance service;
2, Super thin and light with aluminum cabinet design.
3, Good anti-UV and anti-oxidation performance.
4, Large viewing distance, 140° in horizontal, 140° in vertical.
5, Excellent flatness and no splicing gap between modules
6, Quick installation and removal with facile connection lock
7. After-sales service conducted in USA, parts no need to send back to China;
P2.6 Indoor Rental Led display Panels
P2.6 Indoor Rental Led display Specs
| BIR-II-2X | |
| Physical Pitch(mm) | 2.6mm |
| Pixel Configuration | SMD2121 |
| Pixel Density | 147,456 pixels/sqm |
| Module Dimensions (W × H) (mm) | 250x250 |
| Panel Dimensions (mm) | 500x500x80/500x1000x80 |
| No. of Modules Per Panel (W × H) | 2x2/2x4 |
| Physical Resolution of Module (W x H) | 96x96 |
| Physical Resolution of Panel (W x H) | 192x192/192x384 |
| Panel Material | Die-casting Aluminum |
| Single Cabinet Weight | 8/14 kg / panel |
| Gray Scale | 16 bit |
| Colours | 281 trillion |
| Contrast Ratio | 4,000:1 |
| Average Power Consumption | 400 W / ㎡ |
| Max Power Consumption | 800 W / ㎡ |
| Operating Temp/Humidity | -10°-60℃/10%-60% |
| Storage Temp/Humidity | -30°-60℃/10%-60% |
| Refresh Rate | >1,920 Hz |
| Brightness | ≥1,200nits |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing Angle | 140° |
| Expected Lifetime | 100,000 Hrs |
