Product Details:
Payment & Shipping Terms:
|
| Small Pixel Pitch Full Color P1.667 Indoor LED Display For Meeting Room: | P1.87mm | Module Size: | 150*168.75mm |
|---|---|---|---|
| Cabinet Size: | 600*337.5mm | No. Of Modules Per Panel (W*H): | 4*2 |
| Panel Material: | Die-casting | Weight: | 6kg/panel |
| Gray Scale: | 16 Bit | Colours: | 281 Trillion |
| Contrast Ratio: | 2,000:1 | Avg Power Consumption: | 300W/sqm |
| Max Power Consumption: | 600W/sqm | Brightness: | 600~1000nits |
| Refresh Rate: | 2880Hz | Vertical Viewing Angle: | 160° |
| Horizontal Viewing Angle: | 140° | Expect Lifetime: | 100,000Hrs |
| Servicing: | Front | IP Rating: | IP40 |
| Operating Temp/Humidity: | -20℃-50℃/10%-90% | Storage Temp/Humidity: | -40℃-60℃/10%-85% |
| Highlight: | 16bit Indoor HD LED Display,P1.87mm Indoor HD LED Display,P1.87mm Full Color LED Display |
||
600-1000 Nits Indoor HD LED Display Full Color P1.25 IP40 For Meeting Room
Indoor LED Display Specification:
HD LED Display High Definition Fine Pitch Full Color P1.25 Indoor LED Display for Meeting Room
Die-casting Design
The Flatness reaches 0.01mm level, ensuring seamless connection of the screen
Super Light Weight Design
Quick Lock Fast Assemble/Dismantle Saving labour Cost and time
Unique Module Design
Fully Front Access Design, take the modules from front side
Ultra Wide Viewing Angles
Indoor LED Display Parameter:
| Model | UHD-1.2 | UHD-1.5 | UHD-1.8 | UHD-2.3 |
| Pixel Pitch | 1.25mm | 1.56mm | 1.87mm | 2.34mm |
| Cabinet Size | 600*337.5mm | 600*337.5mm | 600*337.5mm | 600*337.5mm |
| Cabinet Weight (kg) | 6 | 6 | 6 | 6 |
| Brightness(cd/m²) | 600~800 | 600~800 | 600~800 | 600~800 |
| Refresh Rate | ≥2880Hz | ≥2880Hz | ≥2880Hz | ≥2880Hz |
| Viewing Angle(H/V) | 160°/140° | 160°/140° | 160°/140° | 160°/140° |
| Power Consumption (Max) W/m² | 600 | 600 | 600 | 600 |
| Power Consumption (Avg) W/m² | 300 | 300 | 300 | 300 |
| IP Rating | IP 40/IP 21 | IP 40/IP 21 | IP 40/IP 21 | IP 40/IP 21 |
Advantage:
Our company also can arrange our engineers to provide you professional installation guide and training for free via remote control, video and phone.
All of products will be tested many times and 100% promise the products are well before shipping.
The products can be customized according to your projects and offer you the CAD drawing for free.
We guarantee all of our displays, modules, spare parts for full two years. During the time, we will replace or fix our goods for free if there is something wrong with them.
Service
1.24-hour hotline service, including counseling and technical guidance.
2. On-line service.
3. Failure maintenance of LED panels.
4. Free professional technical training
5. Paid software upgrade.
6. Warranty service.
7. Engineering technical service.
FAQ:
Q1. Can I have a sample order for LED Display?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Sample needs 3-5 days, mass production time needs 10-15days for order quantity more than
Q3. Do you have any MOQ limit for LED light order?
A: Low MOQ, 1PC for sample checking is available
Q4. Is it OK to print my logo on LED light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q5: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
