| Pixel Pitch: | 4mm | Leds Type: | Nationstar |
|---|---|---|---|
| Driver IC: | ICN2038S Or ICN2153 | Brightness: | 5,500nits |
| IP Rate: | IP65 | Maintenance: | Front |
| Highlight: | P4 Outdoor Rental LED Display,4mm Outdoor Rental LED Display,5500 nits LED Display Video Wall |
||
Front service P4 outdoor fixed led video display wall with 5500nits brightness
P4 led video wall specs
| BOF-B-4 | |
| Physical Pitch | 4 mm |
| Pixel Configuration | SMD 1818 |
| Pixel Density | 62,500 pixels/m² |
| Module Dimensions (W × H) (mm) | 320 × 160 |
| Panel Dimensions (mm) | 960 × 960 × 150 |
| NO .of Modules Per Panel (W × H) | 3 × 6 |
| Physical Resolution of Module (W × H) | 80 × 40 |
| Physical Resolution of Panel (W × H) | 240 × 240 |
| Panel Material | Steel / Aluminum |
| Weight(m²) | 65/45 |
| Processing | 16 bit |
| Colours | 281 trillion |
| Contrast Ratio | 2,000 : 1 |
| Average Power Consumption | 360 W/m² |
| Max Power Consumption | 900 W/ m² |
| Brightness | ≥6500 nits |
| Refresh Rate | ＞1,920 Hz |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing angle | 140° |
| Expected Lifetime | 100, 000 Hrs |
| Servicing | Rear |
| IP Rating | IP 65 |
| Operating Temp/Humidity | -20℃-50℃ / 10%-90% |
| Storage Temp/Humidity | -20℃-50℃ / 10%-90% |
| Scan Method | 1/8 Scan |
Features of P4 outdoor front service display:
1. Front-opened cabinet makes maintenance service easier than normal cabinet;
2. IP65 waterproof cabinet;
3. Automatically shut-down or restart the whole screen with multifunction card
4. 5,500nits brightness makes sharp picture even under sunshine;
