Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | P3.91/P4.81/P5.95 | Leds: | King Light |
|---|---|---|---|
| Panel Material: | Die Casting Aluminum | Controller: | Nova Star |
| Brightness: | >60,00 Nits | Colours: | 281 Trillion |
| Highlight: | 6000 nits Outdoor Rental Led Display,P6.25mm Outdoor Rental Led Display,P6.25mm Outdoor Full Color Led Display |
||
Full Color RGB High Brightness 6500 Nits Outdoor Rental Led Display Wall For Events Show
Product Features
1.High Definition,wonderful visual performance.
2.High brightness ensures the spectators far from the screen can still enjoy what is shown, even under direct sunlight.
3. High resolution could guarantee superior performance even with small screen size.
4.High refresh rate, high grey scale level and high accurate color consistency guarantee the vivid pictures and perfect videos.
5. Super wide viewing angle can be visible in most corners, give you visual enjoyment.
6.SMD technology could guarantee higher flatness and better performance.
7. Aviation plug and quick lock is used, bringing easier cables connection and quicker assembly of cabinets to save time.
8. Low power consumption and fast heat dissipation with dual channel heat dissipation
9. Support a series of detection functions, for example detection of cables failure, detection whether the door of cabinets closed or not, fans` speed monitoring, three-way voltage monitoring and temperature monitoring etc.
Product Parameter
| Physical Pitch | 3.91mm | 4.81mm |
| Pixel Configuration | SMD1921 | SMD2525 |
| Pixel Density |
65,536 pixels/m² |
43,266 pixels/m² |
| Physical Resolution of Module(W*H)(mm) |
64*64/ 64*128
|
52*52/ 52*104
|
| Physical Resolution of Panel(W*H)(mm) |
128*128/ 128*256
|
104*104/ 104*208
|
| Module Dimensions(W*H)(mm) |
250*250/250*500
|
|
| Panel Dimensions(mm) | 500*500*80/500*1000*80 | |
| NO. of Modules Per Panel (W*H) | 2*2 | |
| Panel Material | Die-Casting Aluminum | |
| Colors | 281Trillion | |
| Processing | 16 Bit | |
| Single Cabinet Weight | 9/15kg/panel | |
| Average Power Consumption | 75/150W/panel | |
| Refresh Rate | >1,920 Hz | |
| Brightness | >60,00 nits | |
| Viewing Angle | H:160°/ V:140° | |
| Expected Lifetime | 100,000 Hrs | |
| Servicing | Front/Rear | |
| IP Rating(Front/Rear) | IP 40/IP21 | |
| Max Stacking | 20/10 | |
| Max Hanging | 20/10 | |
Product details
Front Access
lightweight Cabinet
500x500 and 500x1000 panels
IP65 waterproof
Case
Company
Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, focusing on high end professional customers among domestic and overseas markets. BAKOVISION is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION main markets are among America, Europe, Middle East and Asia, all of our products are certificated by RoHS,CCC,CE,FCC,ETL,UL. Standing firmly by quality, winning firmly by proficient, in the past years of development, BAKO VISION continuous growth and brand positioning are all relied onto the long term partnership with variety channel customers over 120+ countries.
Warranty service
1. Free warranty for two year, providing lifetime maintenance service. A certain cost will be charged within a reasonable range after the warranty period. During the warranty period, we are responsible for the maintenance and maintenance of all equipment specified in the contract, and any replacement or repair of any equipment or components caused by product design, installation process, materials, product quality and components. Ensure that the system reaches the design life.
2. Responsible for technical support and version upgrade of related software.
3. During the maintenance period, if the customer has other transformation needs, our company will use its own technical advantages to help customers complete the transformation work in a timely, fast and safe manner.
4. For the original similar items of the customer, if the original manufacturer can not undertake the maintenance work, our company can assist in maintenance and negotiate the cost.
5. If the system fails, our company guarantees to respond within half an hour after receiving the notice.
6. During the maintenance period, when there is no fault, our company also regularly dispatches technicians to overhaul the system without prejudice to the normal use of the customer, and eliminate hidden dangers.
7. Freely train operators for customers, and keep spare parts and spare parts to ensure that they can be handled in the first time when there is a simple failure in the system.
