Product Details:
Payment & Shipping Terms:
|
| Gray Scale: | 16 Bit | Scan Method: | 1/10 |
|---|---|---|---|
| Cabinet Weight: | 28kg/pcs | Cabinet Materials: | Die-casting Aluminum |
| Refresh Rate: | 1920Hz/3840Hz | LED Lamps: | Nationstar/Kinglight |
| Highlight: | SMD2727 Outdoor LED Video Wall,P6.67 Outdoor LED Video Wall,4500nits Event Show LED Panel |
||
P6.67 Outdoor High Resolution Event Show 4K IP65 LED Display Screen LED Panel LED Video Wall
HD Event P6.67 Outdoor Stage Rental LED Display Cabinet Dimension Viewing Angle 160°
Special Features:
1. High quality table lamp, the product quality is stable, reliable, and guaranteed;
2.Viewing angle of 160 degrees or more, multi direction viewing display effect is consistent;
3.Integrated blanking circuit, effectively eliminate the ghost line;
4. Multi rib structure design, to ensure that the product is not easy to tensile deformation, to ensure the integrity of the screen and the consistency of the overall.
5. Support All Media Format and Display Mode:
DVI/HDMI/3G/HD/SD/SDI display mode, applicable for TV program,VCD/DVD and live show.
Smart mode available (optional) to monitor the overall working hours and temperature of each cabinet.
Application
Advertising LED display , shopping mall LED display for logo showing , bank &stock exchange LED display for rates showing ,train & bus station , airport ,school message board, telecommunication LED Screen system for information showing and instruction , Stage performance and so on .
Specification
| Model | BDF-6.67 |
| Pixel Pitch | 6.67mm |
| Pixel Density | 22474 pixels/m2 |
| LED Type | SMD2727 |
| LED Configuration | 1R1G1B |
| Cabinet Dimension | 960X960 mm |
| Cabinet Resolution | 144*144px |
| Cabinet Weight | 28KG |
| Cabinet Material | die casting aluminum |
| Ingress Protection(front/rear) | IP65 |
| Brightness | 4500nits |
| Viewing Angle(H/V) | 160°/160° |
| Driving Method | 1/10 Scan |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | >1920Hz |
| Gray Scale | 16bit |
| Power Consumption(avg.) | 320w/m2 |
| Input Voltage | AC 110/220±10%/50~60Hz |
| Temperature(operating/storage) | -20~50°C / -40~60°C |
| Humidity(operating/storage) | 10%~90%RH / 10%~85%RH |
| MTBF | ≥1000hrs |
| Life Span | ≥50000hrs |
| Pixel Failure | <0.0003 |
Cases
FAQ
1:What is the warranty of your led display?
A:We offer 2 years warranty.and more than 100000 hours screen life span
2:what is your payment term?How long it takes to delivery?
A:We usually accapt the T/T or L/C.both of them will at least 30% deposit in advance,and the rest of 70% will paid before delivery.The lead time is usually 20 day
3:How can you ensure the led display product quality?
A:Before shippment,all the screens have aging test.and then we also have waterproof test and shake test,ensure products can transportation safety and normal use.
4:What is your pre-sale and post-sale service?
A:For pre-sale service,we have professional sales team and technical team,who are willing to answer your question within 24 hours.
For post-sale service,we will instruct you how to install,how to use,how to change the broken moudles,and we can also send the technicals to your country,in general,our led display will not have a big problem,you can rest assured to buy.
Our service:
1. Enquiry response time: within 12hrs.
2. OEM&ODM: design and produce your customized requirements.
3. Provide distributors customized design and models we already have.
4. Protect your sales area, design idea and all your private information.
5. Top quality + reasonable price + patient after-sales service.
6. Brilliant Opto can also offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and LED large screen full color display.
