Product Details:
Payment & Shipping Terms:
|
| Panel Material: | Die Casting Aluminum | Brightness: | 6000 Nits |
|---|---|---|---|
| Servicing: | Rear | IP Rating(Front/Rear): | IP65/IP54 |
| Refresh Rate: | >1,920 Hz | Processing: | 16 Bit |
| Highlight: | SMD2727 Outdoor Fixed Led Display,22376pixels/M2 Outdoor Fixed Led Display,P6.67 Outdoor Led Display Boards |
||
Front service High brightness 5500nit P6.67 outdoor fixed led display for advertising
P6.67 outdoor fixed led display Features:
1. High brightness of 5500nits makes visable under direct sunshine;
2. Front-access module makes easy maintenance;
3. Using high quality parts, like Nationstar leds, Meanwell power supply, etc
P6.67 outdoor fixed led display Specs:
| BOF-B-6 | |
| Physical Pitch | 6.67 mm |
| Pixel Configuration | SMD2727 |
| Pixel Density | 22,376 pixels/m² |
| Module Dimensions (W × H) (mm) | 320 × 160 |
| Panel Dimensions (mm) | 960 × 960 × 150 |
| NO .of Modules Per Panel (W × H) | 3 × 6 |
| Physical Resolution of Module (W × H) | 48 × 24 |
| Physical Resolution of Panel (W × H) | 144 × 144 |
| Panel Material | Steel / Aluminum |
| Weight(m²) | 65/45 |
| Processing | 16 bit |
| Colours | 281 trillion |
| Contrast Ratio | 2,000 : 1 |
| Average Power Consumption | 360 W/m² |
| Max Power Consumption | 900 W/ m² |
| Brightness | ≥6500 nits |
| Refresh Rate | ＞1,920 Hz |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing angle | 140° |
| Expected Lifetime | 100, 000 Hrs |
| Servicing | Rear |
| IP Rating | IP 65 |
| Operating Temp/Humidity | -20℃-50℃ / 10%-90% |
| Storage Temp/Humidity | -20℃-50℃ / 10%-90% |
| Scan Method | 1/10 Scan |
FAQ:
1. Do I need air-conditioner?
YES, if your local temperature is very high . The quantity depends on your dimension.
2. How to install led display?
We will provide drawings of steel structure or Teamviewer to help you install. If you need our engineers to help you, we can sent them to your installation place. But all the fees including air tickets(back and forth), transportation, living and
salary(USD80/per day/per person) need to be paid by you.
3. How to ship?
It's suggested by sea because the cost is much cheaper than by air.
4. Can I do wireless?
Yes, we can provide a set of control system to help you realize that. But I suggest you use computers, especially for your large size, because using computers can bring much better visual effect and better for outdoor advertising .
5. If some issues happen what can I do?
We will do Teamviewer to help you fix all issues.
6. Can you provide the frame for me?
Yes, we can. But we suggest you buy it at local. Firstly, it is difficult to delivery. Secondly, the freight cost will be higher. We can provide detailed drawing of installation to guide you. So no worries about the installation.
