Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 2.97mm | Pixel Density: | 112,896pixels/m2 |
|---|---|---|---|
| Cabinet Dimension: | 500x1000mm | Cabinet Material: | Die Casting Aluminum |
| Ingress Protection(front/rear): | IP40 | MTBF: | ≥1000hrs |
| Pixel Failure: | <0.0003 | ||
| Highlight: | P2.97 Stage Rental LED Display,112896pixels/Sqm Stage Rental LED Display,IP40 Stage Background Led Display |
||
Light weight 16 bit P2.97 Indoor Rental Led display for new product launch
P2.97 Indoor Rental Led display Features
1, High brightness uniformity and color uniformity(≥95%).
2, Super thin and light with aluminum cabinet design.
3, Good anti-UV and anti-oxidation performance.
4, Large viewing distance, 140° in horizontal, 140° in vertical.
5, Excellent flatness and no splicing gap between modules
6, Quick installation and removal with facile connection lock
P2.97 Indoor Rental Led display Specs
| BIR-II-2 | |
| Physical Pitch(mm) | 2.97 |
| Pixel Configuration | SMD2121 |
| Pixel Density | 112896pixels/sqm |
| Module Dimensions (W × H) (mm) | 250x250 |
| Panel Dimensions (mm) | 500x500x80/500x1000x80 |
| No. of Modules Per Panel (W × H) | 2x2/2x4 |
| Physical Resolution of Module (W x H) | 52x52 |
| Physical Resolution of Panel (W x H) | 104x104/104x208 |
| Panel Material | Die-casting Aluminum |
| Single Cabinet Weight | 8/14 kg / panel |
| Gray Scale | 16 bit |
| Colours | 281 trillion |
| Contrast Ratio | 4,000:1 |
| Average Power Consumption | 310 W / ㎡ |
| Max Power Consumption | 750 W / ㎡ |
| Operating Temp/Humidity | -10°-60℃/10%-60% |
| Storage Temp/Humidity | -30°-60℃/10%-60% |
| Refresh Rate | >1,920 Hz |
| Brightness | ≥1,200nits |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing Angle | 140° |
| Expected Lifetime | 100,000 Hrs |
