Product Details:
Payment & Shipping Terms:
|
| Material: | Aluminum | Weight: | 20KG |
|---|---|---|---|
| IP Rating: | IP43/IP54 | Warranty: | 2 Years |
| Light: | Nationstar | Feature: | Acrylic Panel |
| Highlight: | SMD2121 Full Color LED Display,120W Full Color LED Display,IP43 Indoor Stage Led Screen |
||
P6.25 HD Video Dance Floor LED Screen Interactive Dance Floor Screen Support Games
Product Description:
.Quick and Easy Installation
.Ultra Wide Viewing Angle
.Adapt to Multifarious Ground
.IP65 Waterproof
Parameters:
| Floor LED Screen | |
| Physical Pitch | 3.91mm |
| Pixel Configuration | SMD2121 |
| Pixel Density | 65,536 pixels/m² |
| Module Dimensions(W*H)(mm) | 250*250/250*500 |
| Panel Dimensions(mm) | 500*500*80/500*1000*80 |
| NO. of Modules Per Panel (W*H) | 2*2 |
| Panel Material | Die-Casting Aluminum |
| Colors | 281Trillion |
| Processing | 16 Bit |
| Physical Resolution of Module(W*H)(mm) | 64*64/64*168 |
| Physical Resolution of Panel(W*H)(mm) | 128*128/128*256 |
| Single Cabinet Weight | 7/13kg/panel |
| Average Power Consumption | 60/120W/panel |
| Max Power Consumption | 110/400W/panel |
| Brightness | 900-1200 nits |
| Viewing Angle | H:160°/ V:140° |
| Expected Lifetime | 100,000 Hrs |
| Servicing | Front/Rear |
| IP Rating(Front/Rear) | IP 40/IP21 |
| Refresh Rate | >1,920 Hz |
Features:
(1) Interactive Floor and Touch module, The module is equipped with sensors and corresponding IC. Make the video more humanize.
(2) Cabinet Size: 500mm*500mm. Fast locks design, cabinets can be easily assemblied in 7 seconds.
(3) Acrylic Waterproof Interactive Dance Floor led screen.
(4) Strong bearing capacity, strong and dearable Aluminum cabinet,highly load earable.
(5) Professional cooling channel design, to ensure that the screen body heat export quickly and efficiently, make product performance is not affected by heat .
Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005,a world class manufacturer of
technologically advanced LED displays,it is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION product lines have include I/O rantal,I/O fixed, UHD fine pitch, transparent screen,advertising poster,foldable screen… meanwhile, based on our experienced R&D team,and comprehensive management , we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
FAQ
Q1:How to choose a proper led screen for your need?
A:You just need to think of 3 simple questions when you choose a led screen by yourself.
1.Will you use it indoor or outdoor?
2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in one place forever)?
3.what is the appoximate size of the led screen you would like to purchase?
Q2:Which pixel pitch should i choose?
A:There are many different pixel pitch from 1.667--20,25,30mm, there is a roughly principle-usually small pixel(1.667mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen(for example high way huge advertisement).
Q3:Which control system should i choose?
A:There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than 20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.
Our Service:
Pre-sale service
Service 1:online 24 hours and if you need the signs very urgently
Service 2: we can make the professional design for you free. and make the 3D drawing show you how the signs look like when it been finished.
Service 3:Our Qc team will check products'quality/size/style/quanity/accessories/packgae etc after
finishing .if all goods meet customers requirement,we will contact our forwarder and ship all items out.
Service 4:After shipping out, we will provide the tracking number to track your goods status.
After service
Service 1: if the signs have any problems in 2 years, just take the photos show us, we will send the new items
to you free in 10 days. and we pay the freight.
Service 2 :if you are satisfied with our products and place your second/third/.....order from us , more discount
are waiting for you.
