Product Details:
Payment & Shipping Terms:
|
| Physical Pitch: | P2.6/P2.97/P3.91/P4.81mm | Module Size: | 250*250mm |
|---|---|---|---|
| Cabinet Size: | 500*500mm/500*1000mm | No. Of Modules Per Panel (W*H): | 2*2/2*4 |
| Panel Material: | Die-casting | Weight: | 8kg/ 14kg Per Panel |
| Gray Scale: | 16 Bit | Colours: | 281 Trillion |
| Contrast Ratio: | 2,000:1 | Avg Power Consumption: | -10℃-60℃/10%-60% |
| Storage Temp/Humidity: | -30℃-60℃/10%-60% | ||
| Highlight: | P4.81 Indoor Rental LED Display,SMD2121 Indoor Rental LED Display,P3.91 Indoor Led Display Board |
||
Indoor Rental LED Dsiplay P2.6/P2.9/P3.91/P4.81 Full Color High Definition Rental Stage
LED Screen Feature:
LED Screen Parameter:
| BIR-II-3 | BIR-II-4 | |
| Physical Pitch | 3.91mm | 4.81mm |
| Pixel Configuration | SMD2121 | SMD2121 |
| Pixel Density | 65,536 pixels/m² |
43,264 pixels/m² |
| Module Dimensions(W*H)(mm) | 250*250 | 250*250 |
| Panel Dimensions(mm) | 500*500*75/500*1000*75 | 500*500*75/500*1000*75 |
| NO. of Modules Per Panel (W*H) | 2*2/2*4 | 2*2/2*4 |
| Physical Resolution of Module(W*H)(mm) | 64*64 | 52*52 |
| Physical Resolution of Panel(W*H) | 128*128/128*256 | 104*104/104*208 |
| Panel Material | Die-casting Aluminum | Die-casting Aluminum |
| Single Cabinet Weight | 8/14kg/panel | 8/14kg/panel |
| Processing | 16bit | 16bit |
| Colours | 281 trillion | 281 trillion |
| Contrast Ratio | 4,000:1 | 4,000:1 |
| Average Power Consumption | 64/128 W/panel | 64/128 W/panel |
| Max Power Comsunption | 192/382 W/panel | 192/382 W/panel |
| Operating Temp/Humidity | -10ºC-60ºC/10%-60% | -10ºC-60ºC/10%-60% |
| Storage Temp/Humidity | -30ºC-60ºC/10%-60% | -30ºC-60ºC/10%-60% |
| Refresh Rate | >1,920 Hz | >1,920 Hz |
| Brightness | ≥1,200 nits | ≥1,200 nits |
| Horizontal Viewing Angle | 160° | 160° |
| Vertical Viewing Angle | 140° | 140° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs |
| Max Stacking | 20/10 | 20/10 |
| Max Hanging | 20/10 | 20/10 |
| Servicing | Front/Rear | Front/Rear |
| IP Rating(Front/Rear) | IP40/ IP21 | IP40/ IP21 |
1.Light weight: it can be loaded by one person, quick assembling, quick maintain, reduce. carrying, save costs.
2.Thin cabinet: the thickness is only 80mm, the space of the screen is small , and the entire screen will be more beautiful.
3.Flat screen: smooth surface error is under 0.2cm, it can remove the mosaic phenomenon effectively. The effect of the display will be more clear and exquisite.
4. Quick dismounting: adopt fast locking structure connected, firm, quick, beautiful. Tools free installation. Cable-less between modules.
5. Low release heat: low noise, low consumption, low cost, no fan design but excellent thermal design and excellent thermal dispersion.
6.Concave and convex setup support: client can asselbly any shape of the led wall display to make different show effect compare with common led display panel.
7. The products are based on CE,UL,CCC,RoHS
Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005,a world class manufacturer of
technologically advanced LED displays,it is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION product lines have include I/O rantal,I/O fixed, UHD fine pitch, transparent screen,advertising poster,foldable screen… meanwhile, based on our experienced R&D team,and comprehensive management , we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
FAQ
Q1:How to choose a proper led screen for your need?
A:You just need to think of 3 simple questions when you choose a led screen by yourself.
1.Will you use it indoor or outdoor?
2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in one place forever)?
3.what is the appoximate size of the led screen you would like to purchase?
Q2:Which pixel pitch should i choose?
A:There are many different pixel pitch from 1.667--20,25,30mm, there is a roughly principle-usually small pixel(1.667mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen(for example high way huge advertisement).
Q3:Which control system should i choose?
A:There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than 20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.
