| Pixel Pitch: | 3.91mm | Pixel Density: | 65536 Pixels/m2 |
|---|---|---|---|
| Cabinet Size: | 500*500/500*1000mm | LED Lamps: | SMD2121 |
| Weight: | 7/14KG/SQM | ||
| Highlight: | 1200 Nits Indoor Led Wall,P3.91 Indoor Fixed Led Display |
||
Product Description
1.Light weight: it can be loaded by one person, quick assembling, quick maintain, reduce. carrying, save costs
2.Thin cabinet: the thickness is only 62mm,the space of the screen is small,and the entire screen will be more beautiful.
3.Flat screen: smooth surface error is under 0.1cm, it can remove the mosaic phenomenon .effectively. The effect of the display will be more clear and exquisite.
4. Quick dismounting: adopt fast locking structure connected, firm, quick, beautiful.
Specification
| Model | BIR-II-3 |
| Pixel Pitch | 3.91mm |
| Pixel Density | 65536 pixels/m2 |
| LED Type | SMD2121 |
| LED Configuration | 1R1G1B |
| Cabinet Dimension | 500*500mm |
| Cabinet Resolution | 128*128pixels |
| Cabinet Weight | 7kg |
| Cabinet Material | aluminum |
| Ingress Protection(front/rear) | IP40/IP21 |
| Brightness | >1200nits |
| Viewing Angle(H/V) | 140°/140° |
| Driving Method | 1/16 Scan |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | >1500Hz |
| Gray Scale | 16bit |
| Power Consumption(avg.) | 280w/m2 |
| Input Voltage | AC 110/220±10%/50~60Hz |
| Temperature(operating/storage) | -20~50°C / -40~60°C |
| Humidity(operating/storage) | 10%~90%RH/10%~85%RH |
| MTBF | ≥1000hrs |
| Life Span | ≥100000hrs |
| Pixel Failure | <0.0002 |
FAQ
Q1. How to proceed an order for LED display?
1.let us know your demands or application.
2.We give you offer according to your requirements or our suggestions.
3.You confirms the offer and documents then pay deposit for start order.
4.We arrange the production,and inform you producing status.
Q2. What about the lead time?
LED Module and Parts: 1-7working days LED Display Panels: 5-20working days
Q3. Do you have any MOQ limit for led light order?
A: Sample for checking is available
Q4. What about shipping and how long does it take to arrive?
1.Our nearest ports are Shenzhen ,Guangzhou or Hongkong.
2.By Express: 5 - 7 Days / By Air:5 - 10 Days / By Sea: 20 - 40 Days.
3.Delivery to your address directly,and you just wait the items at your door and no need do anything.
Q5. You can print my logo on led display?
Can, Please send us your LOGO design and confirm with us before our production.
Q6. The display received in parts?I have to install each part together?
Yes, but it's quite easy. We will send you the instruction and also can remote to support you for operate the software, everything.
Q7: How about guarantee and deal with the faulty?
1.2-5 years warranty.
2.Make sure 100% no quality problems before shipping.
3.Provide 1% free main parts of module and power supply, and suggust you buy more parts for long time maintenance,and guide you how to repair. 4.For defective batch products, we will repair them and resend to you or send you a new led screen or refound you the payment.
