Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 6.67mm | Moudel Size: | 320*160mm |
|---|---|---|---|
| Cabinet Size: | 960*960mm | Cabinet Material: | Steel/Aluminum |
| Pixel Density: | 22,376 Pixels/m2 | Pixel Configuration: | SMD2727 |
| Highlight: | 6000 Nits Led Display Signs,P6.67 Outdoor Led Display Boards |
||
Product Introduction
1. Seamless Connection and Easy Installation,0.1mm gapline between 2 cabinets.
2. Cost Saving for Installation and Maintenance
3. Dual-maintenance, no need fan, noiseless, low power comsumption.
4. Vertical / Horizontal viewing angle 160 degree.
5. Calibration for high quality picture.
Product feature
1. Thanks to the SMD triad technology, the screen is capable of wide viewing angle, smoother surface and stability.
2. Seamless splicing.
3, High gray level and lower brightness delivers good display performance and vivid image.
4. Quick installation and easy maintenance, front or rear maintenance.
Specification
| Model | BOF-6.67 |
| Pixel Pitch | 6.67mm |
| Pixel Density | 22,376 pixels/m2 |
| LED Type | SMD2727 |
| LED Configuration | 1R1G1B |
| Cabinet Dimension | 960*960mm |
| Cabinet Resolution | 144*144pixels |
| Cabinet Weight | 60kg/45kg |
| Cabinet Material | Steel/aluminum |
| Ingress Protection(front/rear) | IP65 |
| Brightness | >6000nits |
| Viewing Angle(H/V) | 160°/160° |
| Driving Method | 1/10 Scan |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | >1920Hz |
| Gray Scale | 16bit |
| Power Consumption(avg.) | 270w/m2 |
| Input Voltage | AC 110/220±10%, 50~60Hz |
| Temperature(operating/storage) | -20~50°C / -40~60°C |
| Humidity(operating/storage) | 10%~90%RH / 10%~85%RH |
| MTBF | ≥1000hrs |
| Life Span | ≥100000hrs |
| Pixel Failure | <0.0002 |
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
