Product Details:
Payment & Shipping Terms:
|
| Physical Pitch: | P6.67mm | Module Size: | 320*320mm |
|---|---|---|---|
| Cabinet Size: | 960*960mm | No. Of Modules Per Panel (W*H): | 3*3 |
| Panel Material: | Steel/Aluminum | Weight: | 65/45 Kg/sqm |
| Gray Scale: | 16 Bit | Colours: | 281 Trillion |
| Contrast Ratio: | 2,000:1 | Avg Power Consumption: | 360W/sqm |
| Max Power Consumption: | 900W/sqm | Brightness: | 6500nits |
| Refresh Rate: | 1920Hz | Vertical Viewing Angle: | 160° |
| Horizontal Viewing Angle: | 140° | Expect Lifetime: | 100,000Hrs |
| Servicing: | Front | IP Rating: | IP65 |
| Operating Temp/Humidity: | -20℃-50℃/10%-90% | Storage Temp/Humidity: | -20℃-50℃/10%-90% |
| Highlight: | led digital billboard,outdoor led billboard |
||
Billboard LED Display Outdoor Full Color Front Service LED Display for Advertising Sign
Billboard LED Display Features:
1. High difinition, wonderful visual performance;
2. Multifunctional Module Buckle
Special multifuntional module buckle designed for adjusting gaps between module and cabinet to ensure the smoothness and alignment
3. Outdoor Rated
IP65
Brightness adjustable for day and night
Durable LED for 7/24 work mode
4. Fast Installation and Easy Maintenance
Fast lock system guarantees a quick and easy installation
Mechanica Front Access
5. Energy-Saving Technology
Cutting edge'cold display' technology
60% power lower than nomal
50% temperature less than normal
6.The products based on CE, FCC, RoHS Certification;
7. High Gray Scale
8. Different Installation
Billboard LED Display Specification
| Model | BOF-F |
| Pixel Pitch | 6.67mm |
| Pixel Density | 22376 pixels/m2 |
| LED Type | SMD3535 |
| LED Configuration | 1R1G1B |
| Cabinet Dimension | 960mm*960mm |
| Cabinet Resolution | 144*144pixels |
| Cabinet Weight | 65kg |
| Cabinet Material | Die-casting |
| Ingress Protection (front/rear) |
IP65/IP54 |
| Brightness | >6500nits |
| Viewing Angle(H/V) | 140°/140° |
| Driving Method | 1/6 scan |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | >1500Hz |
| Gray Scale | 16bit |
| Power Consumption(avg. ) | 300W/m2 |
| Input Voltage | AC 110/220±10% 50~60Hz |
| Temperature (operating/storage) |
-20~50°C / -40~60°C |
| Humidity(operating/storage) | 10%~90%RH / 10%~85%RH |
| MTBF | ≥1000hrs |
| Life Span | ≥100000hrs |
| Pixel Failure | <0.0003 |
Company Information:
Shenzhen Bako Technology Co. Limited is a full range manufacturer and LED display solutions provider and its ancillary systems worldwide since 2009, headquartered in Shenzhen with a 6, 000m² production state of the art facility to cover international demands. We provide a one-stop shopping in the design, production, and distributions of LED displays and solutions for our customers domestically and globally.
Our products include ranges of indoor, outdoor, fixed, rental and creative LED Solutions for various applications including sports, advertisement, concerts, shopping malls, stadiums, exhibitions or any other indoor and outdoor events that comes to your imagination.
We strictly follows ISO9001: 2008 quality management system and passed CE, FCC, UL, RoHS, CCC etc. All of these factors ensure high quality LED products and effective services.
We keep the company culture ``Professional, Concentration, Focus`` aimed at LED. With the development of LED technology and the perfervid competition in the LED field.
Advantage:
Our company also can arrange our engineers to provide you professional installation guide and training for free via remote control, video and phone.
All of products will be tested many times and 100% promise the products are well before shipping.
The products can be customized according to your projects and offer you the CAD drawing for free.
We guarantee all of our displays, modules, spare parts for full two years. During the time, we will replace or fix our goods for free if there is something wrong with them.
