Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 4.81 | Cabinet Dimension: | 500*500/500*1000 |
|---|---|---|---|
| IP Rating: | IP65/IP54 | Brightness: | >6,000 |
| Servicing: | Front/Rear | Driving Method: | 1/16 Scan |
| Gray Scale: | 16bits | Control System: | Novastar |
| Highlight: | indoor full color led display,indoor led billboard |
||
3.91mm Pixel Rental LED Wall Display Tools Free Installation Advertising Backdrop
Our indoor LED wall screens come in modules that are 500mm x 500mm in size, with a 3.91/4.81mm pitch. This indoor screen able to deliver a superior contrast ratio due to the use of blackbody LEDs which are non-reflective. A high contrast ratio is critical as it creates a display that can produce vivid colors with excellent uniformity for beautiful images every time.
Parameters:
| Module | |
| Pixel Pitch | 4.81mm |
| Pixel Density | 43,264 pixel/sqm |
| Pixel Quantity (W * H) | 52* 52/52* 104mm |
| Module Size | 250 * 250/250 * 500mm |
| LED Type | SMD2525 |
| LED Configuration | 1R1G1B |
| Cabinet | |
| Resolution (W * H) | 104* 104/104* 208mm |
| Dimension(mm)(W * H) | 500*500/500*1000mm |
| Cabinet Material | Die-Casting |
| Cabinet Weight | 9/15kg/Panel |
| IP Rating(Front/Rear) | IP65/IP54 |
| Screen | |
| Brightness | >6,000nits |
| Input Voltage | AC 110/220±10% 50~60Hz |
| Gray Scale | 16bits |
| Refresh Rate | >1,920Hz |
| Dot Defects Rate | <0.0001 |
| Viewing Angle (H/V) | 160°/140° |
| Life Span | ≥100000hrs |
| Power Consumption(avg.) | 75/150W/Panel |
| Operating Temp/Humidity | ﹣20d℃～60℃ / 10%～60%RH |
| Storage Temp/Humidity |
﹣30℃～60℃ / 10%～60%RH |
Features:
1 User Friendly and Fast Installation
Truss hanging and ground support both available
Fast Lock and handle designed user friendly
Front and rear access
Tools free installation
2 Floor Screen Available
Durable PC mask and adjustable foot bracket are ready
Interactive effect and radar integration are optional
3 Unsurpassed Color Uniformity
Unique color calibration process
Deep black levels, contrast ratio 4000:1
4 Smart Concave and Convex
Both 500*500mm and 500*1000mm cabinets are arc-able
0°~10° concave and convex degree
Company:
Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005,a world class manufacturer of
technologically advanced LED displays,it is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION product lines have include I/O rantal,I/O fixed, UHD fine pitch, transparent screen,advertising poster,foldable screen… meanwhile, based on our experienced R&D team,and comprehensive management , we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
Q&A:
Q1: How to choose a proper led screen for your need?
A: You just need to think of 3 simple questions when you choose a led screen by yourself.
1. Will you use it indoor or outdoor?
2. Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in one place forever)?
3. what is the appoximate size of the led screen you would like to purchase?
Q2: Which pixel pitch should i choose?
A: There are many different pixel pitch from 1.667--20,25,30mm, there is a roughly principle-usually small pixel(1.667mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen(for example high way huge advertisement).
Q3: Which control system should i choose?
A: There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than 20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.
Q4: How to order from you compamy?
A: You can both place order to us by online or to our company directly offline, before place order welcome to contact us for confirmation.
Q5: How to pay?
A: We accept L/C, T/T bank, or paypal or westerunion.
Q6: How to ship?
A: It is optional and we respect customer's choice. You can choose to ship by air cargo, by DHL(Fedex,UPS etc) internation express company, or by sea according to your goods weight and volume and the delivery time you need.
Q7: How to install it after i received it?
A: We will offer you the drawing to guide you for installation, we could also offer steel drawing, software set up drawing or photo or send our engineer fly to you for help if needed.
