Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 4.81 | Cabinet Dimension: | 500*500/500*1000 |
|---|---|---|---|
| IP Rating: | IP65/IP54 | Brightness: | >6,000 |
| Servicing: | Front/Rear | Driving Method: | 1/16 Scan |
| Gray Scale: | 16bits | Control System: | Novastar |
| Highlight: | indoor full color led display,led publicity screens |
||
4-BIR-II.pdf
Classical and stable structure and performance.
Two patent protected strong locks design, realizing the combination of reliability and security.
Die-casting aluminum body, lightweight for easy transportation and high accuracy installation.
Perfectly be compatible with any existing controller and without screen shaking/quick flashing/mosaic problems.
Supporting installation of hanging/ground mounting, for stage/TV show/studio, and other event applications.
Tool-free assembly and disassembly.
Indoor Rental LED Display Parameters
| Module | BIR-II |
| Pixel Pitch | 4.81mm |
| Pixel Density | 43,264 pixel/sqm |
| Pixel Quantity (W * H) | 52* 52/52* 104mm |
| Module Size | 250 * 250/250 * 500mm |
| LED Type | SMD2525 |
| LED Configuration | 1R1G1B |
| Cabinet | |
| Resolution (W * H) | 104* 104/104* 208mm |
| Dimension(mm)(W * H) | 500*500/500*1000mm |
| Cabinet Material | Die-Casting |
| Cabinet Weight | 9/15kg/Panel |
| IP Rating(Front/Rear) | IP65/IP54 |
| Screen | |
| Brightness | >6,000nits |
| Input Voltage | AC 110/220±10% 50~60Hz |
| Gray Scale | 16bits |
| Refresh Rate | >1,920Hz |
| Dot Defects Rate | <0.0001 |
| Viewing Angle (H/V) | 160°/140° |
| Life Span | ≥100000hrs |
| Power Consumption(avg.) | 75/150W/Panel |
| Operating Temp/Humidity | ﹣20d℃～60℃ / 10%～60%RH |
| Storage Temp/Humidity |
﹣30℃～60℃ / 10%～60%RH |
Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005,a world class manufacturer of
technologically advanced LED displays,it is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION product lines have include I/O rantal,I/O fixed, UHD fine pitch, transparent screen,advertising poster,foldable screen… meanwhile, based on our experienced R&D team,and comprehensive management , we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
FAQ
Q1:How to choose a proper led screen for your need?
A:You just need to think of 3 simple questions when you choose a led screen by yourself.
1.Will you use it indoor or outdoor?
2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in one place forever)?
3.what is the appoximate size of the led screen you would like to purchase?
Q2:Which pixel pitch should i choose?
A:There are many different pixel pitch from 1.667--20,25,30mm, there is a roughly principle-usually small pixel(1.667mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen(for example high way huge advertisement).
Q3:Which control system should i choose?
A:There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than 20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.
