| Physical Pitch: | 4.81mm | Panel Material: | Die-casting Aluminium |
|---|---|---|---|
| Module Size:: | 250mm*250mm | LED Chip: | Nationstar |
| IP Rating:: | IP65 Waterproof | Life Span: | 100,000 Hrs |
| Highlight: | outdoor led screen hire,events led display |
||
Die-casting Aluminum P3.91 Outdoor Waterproof IP65 Moving Video Led Display For Rental
The best assistant of outdoor advertising. Suitable for stage, bank, promotion, exhibition,shopping mall, highway, station, KTV, stadium, airport and all outdoor places.
Product Features:
1. High quality,Advanced and proper system design,cost-effective.Display effect stable, can be completes fast fixed installation.
2. After waterproof test all the cabinets can ensure waterproof properties. The cabinet upper and lower with positioning holes and positioning column.
3. Independent rear cover and lock design, both moisture-proof,dustproof, and can facilitate fast debugging and maintenance cabinet.
4. Display mode:Right and left movement,zola curtain,right in the tabernacle of the congregation,pull open,blinking,namely show and so on.
5.Through program editor software,the words,images and videos can be editted just by clicking the mouse.The edited content is stored in the controller card,and will be broadcasted successively according to the program sheet automatically.
Parameter
| BOR-III-3 | BOR-III-4 | |
| Physical Pitch | 3.91mm | 4.81mm |
| Pixel Configuration | SMD1921 | SMD2727 |
| Pixel Density | 65,536 pixels/m² | 43,264 pixels/m² |
| Module Dimensions(W*H)(mm) | 250*250/250*500 | 250*250/250*500 |
| Panel Dimensions(mm) | 500*500*80/500*1000*80 | 500*500*80/500*1000*80 |
| NO. of Modules Per Panel (W*H) | 2*2 | 2*2 |
| Panel Material | Die-Casting Aluminum | Die-Casting Aluminum |
| Colors | 281Trillion | 281Trillion |
| Processing | 16 Bit | 16 Bit |
| Physical Resolution of Module(W*H)(mm) | 64*64 | 52*52 |
| Physical Resolution of Panel(W*H)(mm) | 128*128/128*256 | 104*104/104*208 |
| Single Cabinet Weight | 9/15kg/ panel | 9/15kg/ panel |
| Average Power Consumption | 75/150W/panel | 75/150W/panel |
| Max Power Consumption | 225/550W/panel | 225/550W/panel |
| Brightness | >60,00nits | >60,00nits |
| Viewing Angle | H:160°/ V:140° | H:160°/ V:140° |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front/Rear | Front/Rear |
| IP Rating(Front/Rear) | IP 65/IP54 | IP 65/IP54 |
| Max Stacking | 20/10 | 20/10 |
| Max Hanging | 20/10 | 20/10 |
| Refresh Rate | >1,920 Hz | >1,920 Hz |
| Contrast Ratio | 4000:1 | 4000:1 |
Products Image
LED Display Module P3.91/P4.81.
This is P3.91/P4.81 indoor led module , module size is 250mm x 250mm , our common type is Sanan chip led , with chipone 2038s IC, we can also produce it with nationstar /kinglight led ,MBI5124IC, or other type as you like .
Wide viewing angle: The horizontal and vertical viewing angles are so wide that it is suitable for wide horizontal
Better Grey Scale Grade
Stable and clear images, excellent dynamic showing, without scanning line, and the effect will be more nature if play point-to-point output image.
Application Case:
Widely used for shopping malls, entertainment venues, wedding hall, government agencies, trade fair, fair, aiming at the exhibition, press conference, meeting rooms, cinemas, airports, hotels, internal, station waiting area, outdoor stadium, and a variety of public facilities and etc.
