| Physical Pitch: | P3, P4, P5, P6, P8, P10 | Brightness: | >6,500 Nits |
|---|---|---|---|
| Servicing: | Rear | LED Lamp: | Nationstar |
| Operating Temp/Humidity: | -20℃- 50℃ / 10% - 90% | Panel Dimensions (mm): | 960 × 960 × 150mm |
| Highlight: | roadside led display,street led screen |
||
Commercial P8mm Outdoor LED Display Billboard IP65 Advertising Board
Digital Billboard Description
BOF-outdoor fixed led display is an high definition media led screen, with IP65 waterproof function and 1920 refresh rate. Suitable brightness adjustable for outdoor day and night. And it is widely used in Semi-outdoor and outdoor advertising ,Competitive price,Long life time and hgih quality.
Digital Billboard Features
1. High resolution
The most apparent features of the new generation of LED display.
2. Black, White, Gray Cabinet to choose
We have three cabinet color to choose. For different country market. When the temperature is too high for a long time, the white box can be used to reduce the heat absorption.
3. Easy maintenance
After adopting the classic back maintenance,it's applied to large size LED and roof mounting,wall mounting and pillar base.
4. Steel or Aluminum material
The steel material is much cheapter than Aluminum, and the steel cabinet can be customized.
The alumunim materials has good resistance to salt spray, strong acid and corrosion resistance, good heat dissipation.
| Physical Pitch | 3.2mm | 4mm | 5mm | 6.67mm | 8mm |
| Pixel Configuration | SMD 1921 | SMD 1818 | SMD 2727 | SMD 2727 | SMD 2727 |
| Pixel Density | 97,656 pixels/m² | 62,500 pixels/m² | 40,000 pixels/m² | 22,376 pixels/m² | 15,625 pixels/m² |
| Module Dimensions (W × H) (mm) | 192 × 192 | 320 × 160 | 320 × 160 | 320 × 160 | 320 × 160 |
| Panel Dimensions (mm) | 960 × 960 × 150 | ||||
| NO.of Modules Per Panel (W × H) | 5 × 5 | 3 × 6 | 3 × 6 | 3 × 6 | 3 × 6 |
| Physical Resolution of Module (W × H) | 60 × 60 | 80 × 40 | 64 × 32 | 48 × 24 | 40 × 20 |
| Physical Resolution of Panel (W × H) | 300 × 300 | 240 × 240 | 192 × 192 | 144 × 144 | 120 × 120 |
| Panel Material | Steel / Aluminum | ||||
| Weight (m²) | 65 / 45 | ||||
| Gray Scale | 16 bit | ||||
| Colours | 281 trillion | ||||
| Contrast Ratio | 2,000 : 1 | ||||
| Average Power Consumption | 360 W/m² | ||||
| Max Power Consumption | 900 W/m² | ||||
| Average Power After Energy Saving | - | - | - | 90 W/m² | 90 W/m² |
| Max Power After Energy Saving | - | - | - | 230 W/m² | 230 W/m² |
| Brightness | >6,500 nits | ||||
| Refresh Rate | >1,920 Hz | ||||
| Viewing Angle | 160°(V)140°(H) | ||||
| Expected Lifetime | 100,000 Hrs | ||||
| Servicing | Rear | ||||
| IP Rating | IP65 | ||||
| Operating Temp/Humidity | -20℃- 50℃ / 10% - 90% | ||||
| Storage Temp/Humidity | -20℃-50℃ / 10% - 90% | ||||
| Scan Method | 1/16 Scan | ||||
