Product Details:
Payment & Shipping Terms:
|
Material: | Die-Casting Aluminum | Light: | Nationstar |
---|---|---|---|
Driver IC: | MBI5124 | Application: | Indoor Rental |
Warranty: | 2 Years | Expected Lifetime: | More Than 100,000Hrs |
Brightness: | 1200 Cd/sqm | ||
Highlight: | led publicity screens,indoor led billboard |
Indoor Stage Rental Led Display SMD Lightweight Aluminum Video Wall Panel 2880Hz
Product Description
LED is the abbreviation for light emitting diode. LEDs are arranged in vertically and horizontally with a stable pitch that forms LED matrix LED Display Screen. Each of the LED Display has a corresponding brightness control circuit. The computer controls the circuit, which affects the brightness of each LED and then forms the image we want in the LED display.
Parameters:
Pixel Pitch | 3.91mm |
Pixel Density | 65536dots/sqm |
Color Configuration | 1R1G1B |
LED Package | SMD2121 |
Module Size | 250mm x 250mm |
Module Resolution | 64dots x 64dots |
Drive Mode | 1/16 Scan |
Cabinet Material | Die casting Aluminum |
Led Color | Black |
Standard Cabinet Size | 500mm x 1000mm |
Cabinet Weight | 14KG |
Brightness | ≥1300 cd/sqm, adjustable by software |
Viewing Distance | 4m-40m |
Viewing Angle | H: 140°; V:140° |
Features:
1. Quick installation & maintenance
2. Stronger & more accurate cabinet frame
3. High definition & resolution
4. Better consistency
5. Ultra slim & light weight
6. Can be front service
7.Metal power box for better heat dissipation
8. High cost-effective
Company Introduction:
Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005,a world class manufacturer of
technologically advanced LED displays,it is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.
BAKO VISION product lines have include I/O rantal,I/O fixed, UHD fine pitch, transparent screen,advertising poster,foldable screen… meanwhile, based on our experienced R&D team,and comprehensive management , we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.
FAQ
Q1:How to choose a proper led screen for your need?
A:You just need to think of 3 simple questions when you choose a led screen by yourself.
1.Will you use it indoor or outdoor?
2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in one place forever)?
3.what is the appoximate size of the led screen you would like to purchase?
Q2:Which pixel pitch should i choose?
A:There are many different pixel pitch from 1.667--20,25,30mm, there is a roughly principle-usually small pixel(1.667mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen(for example high way huge advertisement).
Q3:Which control system should i choose?
A:There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than 20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.
