| Pixel Configuration: | SMD 3535 | Optional Models: | Outdoor P5,P6.67,P8,P10 |
|---|---|---|---|
| Panel Material: | Steel/ Aluminum | Panel Size: | Customized Size |
| Gray Scale (mm): | 16bit | Module Demensions (W*H)(mm): | 320 * 160mm |
| Refresh Rate: | >1920 Hz | ||
| Highlight: | roadside led display,outdoor waterproof led advertising panels |
||
Outdoor Fixed LED Display Front Maintenance Fast Installation P6/P8/P10 Full Color 6500nits Screen
Outdoor Fixed LED Display Description:
1. P10 SMD/ DIP Outdoor Commercial Led Display is being widely choose for large size outdoor LED billboards projects;
2. Standard LED cabinet of IP65,waterproof and dustproof;
3. High brightness up to 7000cd,and special requirement LED screen projects can reach 10,000nits;
4, The LED billboards present clear vivid image and video even under direct sunshine;
5. Short best view distance,for P10 DIP/SMD Outdoor Commercial Led Display,the best view distance is above 8 meters;Audience/potential consumers people passed by would enjoy a clear image that standing above 8 meters.
6. Waterproof for outdoor environment use.
Outdoor Fixed LED Screen Specification:
| Pixel Pitch | P4.81 | P6.67 | P8 | P10 |
| LED Type | SMD2727 | SMD2727 | SMD3535 | SMD3535 |
| Module Size | 250*250 | 320*320 | 256*256 | 320*320 |
| Cabinet Size | 1000*1000*150 | 1280*960*150 | 1280*768*150 | 1280*960*150 |
| Module Resolution | 52*52 | 48*48 | 32*32 | 32*32 |
| Cabinet Weight | 65/45kg | |||
| Cabinet Material | Steel/ Aluminum | |||
| Gray Scale | 16 bit | |||
| Contrast Ratio | 2000:1 | |||
| View Angle(H/V) | 160°/ 140° | |||
| Refresh Rate | >1920Hz | |||
| Brightness | >6500nits | |||
| IP Rating | IP65 / IP54 | |||
| Servicing | Front / Rear | |||
| Operating Temp/Humidity | -20ºC-50ºC / 10%-90% | |||
| Expected Lifetime | 100,000Hrs | |||
| Average Power Consumption | 360W/ Panel | |||
Outdoor Fixed LED Screen Product Features:
1. Durable fresh color and high brightness by adopting high quality LEDs.
2. Energy saving 24% by using high efficiency IC driver and improved PCB design.
3. Persistent Uniformity, contrast and flatness of outdoor LED screen, increasing the profit and competitiveness of the operator.
4. Anti-UV module mask, Anti-Oxidation module frame with protection from deformation.
5. Aircraft-grade connectors of the power, signal to ensure stable connection and high reliability.
6. IP65 protection grade, durable nature to enable the outdoor LED screen working in all weather outdoor environments.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
