Product Details:
Payment & Shipping Terms:
|
| Panel Material: | Die Casting Aluminum | Brightness: | >6,000 Nits |
|---|---|---|---|
| Servicing: | Rear | IP Rating(Front/Rear): | IP65/IP54 |
| Refresh Rate: | >1,920 Hz | Processing: | 16 Bit |
| Led Type: | SMD3535 | Power Supply: | Meanwell Or G-energy |
| Highlight: | roadside led display,street led screen |
||
Low temprature performance nergy-saving 6000nits P10 Outdoor Fixed LED Display
P10 Outdoor Fixed LED Display Specs:
| BOF-F-10 | |
| Physical Pitch | 10 mm |
| Pixel Configuration | SMD 3535 |
| Pixel Density | 10,000 pixels/m² |
| Module Dimensions (W × H) (mm) | 320 × 160 |
| Panel Dimensions (mm) | 1280 × 960 × 150 |
| NO .of Modules Per Panel (W × H) | 4 × 6 |
| Physical Resolution of Module (W × H) | 32 × 32 |
| Physical Resolution of Panel (W × H) | 96 × 96 |
| Panel Material | Steel / Aluminum |
| Weight(m²) | 65/45 |
| Processing | 16 bit |
| Colours | 281 trillion |
| Contrast Ratio | 2,000 : 1 |
| Average Power After Energy Saving | 150 W/ m² |
| Max Power After Energy Saving | 400 W/ m² |
| Refresh Rate | ＞1,920 Hz |
| Brightness | ≥6500 nits |
| Vertical Viewing Angle | 160° |
| Horizontal Viewing angle | 140° |
| Expected Lifetime |
100, 000 Hrs
|
P10 Outdoor Fixed LED Display Features:
1. Saving about 35% electricity comparing with ordinary led display;
Under the full white testing, ordinary cabinet power consumption is 624watt/cabinet,
while energy saving cabinet power consumption is only 404watt/cabinet, up to 35% energy is saved;
2. Lower temprature performance with enery-saving display, like following picture shows.
Lower temprature makes longer lifetime of led display.
3. one power supply with different voltage output(+3.8V, +2.8V) which feed red led and blue green leds seperately;
Advantages of Shenzhen Bako Vision Technology Co., Ltd
1. We are stock-listed company with 15 years experience in led display industry;
2. 20,000sqm workshop with 600 workers, 100 senior engineers;
3. Export to 200 countries, 98% of them get positive feedback;
4. Won Reddot award;
5. We not only offer high quality products, but offer full package solution, like design, installation, training, etc.
For example, once the order is fixed, we will make design for framework for our client's reference, like following shows
We also will send engineer to inspect the installation location on site, and during installation our engineer will guide our clients to do installation.
