Product Details:
Payment & Shipping Terms:
|
| Gray Scale: | 16 Bit | Colors: | 281 Trillions |
|---|---|---|---|
| Driving Mode: | 1/4 Scan | Expected Lifetime: | 100,000 Hrs |
| Brightness: | >6500 Nits | Power Supply: | AC 110/220±10% 50~60Hz |
| Highlight: | truck mounted led screen,led advertising trailer |
||
Outdoor Mobile Trailer Mounted Led Panel Display For Commercial Advertising
Main Feature
1. The protection level can reach up to IP65 ,and applicable to any rainy weather ,thus can used in any outdoor environment.
2. Wider viewing angle: Horizontal≥120º;Vertical≥120º,can attract more audiences'eye, very good for outdoor advertising.
3. Customized available: Cabinet size and materials can be customized according different projects.Our mobile LED screen trucks are very quick to setup, and are completely self-contained allowing for extreme flexibility.
4.We take Pixel-To-Pixel Calibration System to make the shows image effectively stable.
5. A module mask had mounted, anti-Oxidation module frame with protection from deformation.
6. Another feature of truck mobile LED display is the movable power supply control room, which not only facilitates control, but also reduces unnecessary power consumption.
Specifications
| Truck mobile billboard | ||
| Pixel Pitch | 4.81mm | 6.67mm |
| Pixel Density | 15,625 px/m2 | 10,000 px/m2 |
| LED Type | SMD2727 | SMD2727 |
| LED Configuration | 1R1G1B | 1R1G1B |
| Cabinet Dimension | 1000*1000 mm | 1280*960mm |
| Cabinet Resolution | 208*208 px | 192*144 px |
| Cabinet Weight | 60kg | 60kg |
| Cabinet Material | cold steel | cold steel |
| Ingress Protection(front/rear) | IP65/IP54 | IP65/IP54 |
| Brightness | >6500nits | >6500nits |
| Viewing Angle(H/V) | 140°/160° | 140°/160° |
| Driving Method | 1/4 Scan | 1/4 Scan |
| Power Consumption(avg.) | 360w/m2 | 360w/m2 |
| Frame Refresh | ≥ 60Hz | ≥ 60Hz |
| Data Refresh Rate | ≥ 1920Hz | ≥ 1920Hz |
| Gray Scale | 16bit | 16bit |
| Power Supply | AC 110/220±10%,50~60Hz | AC 110/220±10%,50~60Hz |
| Temperature(operating/storage) | -40ºC - 60ºC | -40ºC - 60ºC |
| Humidity(operating/storage) | 10%~90%RH/10%~85%RH | 10%~90%RH/10%~85%RH |
| MTBF | ≥1000 Hours | ≥1000 Hours |
| Life Span | ≥100000 | ≥100000 |
| Pixel Failure | <0.0003 | <0.0003 |
Applications:
Our full color LED display are widely used in chain shop,large shopping mall, hospitals,bars,shopping mall,outdoor,advertising media,Entertainment centers,Square and so on .
Advantages
Our Promise
24 hours response for your inquiry.
7 days per week to help you.
365 days after serbice support.
All lifetime guarantee and free charge within two years.
OEM&ODM, CUSTOMIZED DESIGN SERVICE,
Patent right protection and distributorship protection.
