Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 4.81mm | Pixel Density: | 43,264 Pixels/㎡ |
|---|---|---|---|
| Panel Size: | 500 X 500 X 80mm/ 500 X 1000 X 80mm | Cabinet Weight: | 7 / 13 Kgs/cabinet |
| Brightness: | 1100nits | Refresh Rate: | ＞1,920 Hz |
| Highlight: | led publicity screens,indoor led billboard |
||
SMD2121 P4.81 Fanless Indoor Advertising Led Display Screen High Resolution Full Color
Retal Led Screen Specifiction:
| Physical Pitch | 4.81mm |
| Pixel Configuration | SMD2121 |
| Pixel Density | 43,264 pixels/m² |
| Module Dimensions | 250×250mm/250×500mm |
| Panel Dimensions | 500×500×80mm/500×1000×80mm |
| Physical Resolution of Panel | 104×104dots/104×208dots |
| Panel Material | Die-Casting Aluminum |
| Single Cabinet Weight | 7kg/panel |
| Grayscale | 16bit |
| Colors | 281trillion |
| Contrast Ratio | 4000:1 |
| Average Power Consumption | 60/120W/ ㎡ |
| Max Power Consumption | 110/400 W/ ㎡ |
| Refresh Rate | >1920Hz |
| Brightness | 900 - 1200 nits |
| Expected Lifetime | 100,000Hrs |
| Servicing | Front/Rear |
| IP Rating(Front/Rear) | IP40/IP21 |
Retal Led Screen Features and Advantages:
1. Slim and lightweight. Made with die-casting aluminum, only 7kg per cabinet, 80mm thickness, saving the transportation cost effectively.easy to handle. Die cast aluminum cabinet, perfect splicing without gaps.
2. Special concave and convex design, totally satisfy your requirements.easily attract attention, greatly enhance the value of advertising. You can adjust the screen as ±15° as your wish.
3. Made with die-casting aluminum better for heat dissipation and no fan design very quiet.
4. Fast installation and easy maintenance. Fast lock design guarantees a quick installation without tools. Magnetic modules guarantees a easy maintenance, saving the handling, labour cost effectively.Fast locking makes assembly and disassembly extremely easy. High-quality plugs ensure reliability.
5. Wide viewing angle. 160° for horizontal, 140° for vertical. High contrast ratio and high refresh rate bring you a visual feast and well return.
FAQ
1. How to payment?
We accept the L/C, T/T.
2.What is the packing method?
We usually use plywood case or flight case.
3.How about the delivery time?
We will ship within 15-25 working days after you placed the order.
4.What's the warranty of your Led Poster?
We have a 2-year warranty for our led display screen, and 100,000 hours life span of the led lamps
Our services
Pre-producing
1. Get complete requirements of clients.
2. To do a thorough analysis.
3. Offer a most reasonable and scientific solution.
4. Customized design.
In producing
1.Producing progress updating for clients.
2.Particular installation CAD and design diagram for clients.
After service
1. 2 years free warrenty.
2. 7 days a week, 24 hours a day for 5 years on-line service for any technical support for any customers.
3. Can arrange engineer to go to your place to support your installation and free training.
