Product Details:
Payment & Shipping Terms:
|
| Processing: | 16 Bit | Colours: | 281 Trillion |
|---|---|---|---|
| Contrast Ratio: | 2000:1/4000:1 | Servicing: | Front |
| IP Rating: | IP43/IP54 | Refresh Rate: | >1920 Hz |
| Life Span: | 100,000hrs | Warranty: | 2 Years |
| Highlight: | front maintenance led display,outdoor full color led screen |
||
180 or 360 Degree Lightweight Front Service LED Foldable Display Screen with Hanging Stacking and Attaching14-BF.pdf
Lightweight Front Service LED Foldable Display Feature
Easy and Fast Installation: easy connection design saves 80% labor cost
Variable Foldable Module: 180 or 360 Degree Foldable
Lightweight Front Service LED Foldable Display Specification
| BF-6 | BF-7 | BF-10 | BF-12 | |
| Physical Pitch | 6 mm | 7.8 mm | 10 mm | 12 mm |
| Pixel Configuration | SMD 3528 | SMD 3528 / SMD 3535 | SMD 3528 | SMD 3528 |
| Pixel Density | 27,556 pixels/m² | 16,384 pixels/m² | 10,000 pixels/m² | 6,889 pixels/m² |
| United Size (mm) | 192 × 192 | 250 × 250 | 160 × 160 | 192 × 192 |
| Physical Resolution of Unit ( W× H) | 32 × 32 | 32 × 32 | 16 × 16 | 16 × 16 |
| Weight(kg/m²) | <10 | <9 | <9 | <9 |
| Processing | 16 bit | 16 bit | 16 bit | 16 bit |
| Colours | 281trillion | 281trillion | 281trillion | 281trillion |
| Contrast Ratio | 2,000 : 1 / 4,000 : 1 | 2,000 : 1 / 4,000 : 1 | 2,000 : 1 / 4,000 : 1 | 2,000 : 1 / 4,000 : 1 |
| Average Power Consumtion | 150 / 310 W/m² | 90 / 200 W/m² | 110 W/m² | 75 W/m² |
| Max Power Consumption | 375 / 775 W/m² | 225 / 500 W/m² | 275 W/m² | 187 W/m² |
| Operating Temp/Humidity | -10ºC- 60ºC / 10%-60% | -10ºC- 60ºC / 10%-60% | -10ºC- 60ºC / 10%-60% | -10ºC- 60ºC / 10%-60% |
| Storage Temp/Humidity | -30ºC- 60ºC / 10%-60% | -30ºC- 60ºC / 10%-60% | -30ºC- 60ºC / 10%-60% | -30ºC- 60ºC / 10%-60% |
| Refresh Rate | >1920 Hz | >1920 Hz | >1920 Hz | >1920 Hz |
| Brightness | 2,000 / 4,000nits | 1,500 / 6,000nits | 1,500nits | 1,500nits |
| Foldable Angle | 360° | 360° | 360° | 360° |
| Max Length of Control Box | 6m | 6m | 6m | 6m |
| Expected Lifetime | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs | 100,000 Hrs |
| Servicing | Front | Front | Front | Front |
| IP Rating (Front/Rear) | IP 43 / IP 54 | IP 43 / IP 54 | IP 43 / IP 54 | IP 43 / IP 54 |
Our Services
Pre-sale service:
1. Inquiries will be replied within 24 hours.
2. Market research and forecast for the customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Datasheet and samples offered.
5. Other required services such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking producing procedures all the time.
2. Provide photos and videos as per customer's requirement during production.
After-sale service:
1. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
2. Warranty: 24 months.
3. Free technician training.
4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control
system software CD and so on.
FAQ
Q1. Do you provide samples?is it free or extra?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q2.How to order?
A:Please send us your purchase order by Email or we can make you proforma invoice under your request.
We need to know the following information for your order before sending you PI.
1)Product information-Quantity,Specification(Size,Material,Technological if needed and Packing requirements etc.
2)Delivery time required.
3)Shipping information-Company name,Street address,Phone&Fax number,Destination sea port.
4)Forwarder's contact details if there's any in China.
Q3. Do you offer guarantee for the products?
A: Yes,we offer 2-5 years warranty to our products.
