Product Details:
Payment & Shipping Terms:
|
| Pixel Density: | 160000 Pixels/m² | Pixel Configuration: | SMD2121 |
|---|---|---|---|
| Gray Scale: | 16 Bit | Life Span: | ≥50000hrs |
| MTBF: | ＞1000hrs | IP Rating(front/rear): | IP40/IP21 |
| Highlight: | front maintenance led display,outdoor full color led screen |
||
Fine Pitch Front Service LED Panel P1.87 P2.5 Fixed LED Panel
Fine Pitch LED Panel Features:
1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.
Fine Pitch LED Panel Advantages:
1. 16:9 Golden division ratio
It can be point to point spliced to the led screen of standard 720P ,1080P ,2160P , 3840P ,etc.
2. Ultra high definition
It delivers a truly amazing picture with extraordinary pixels producing an image that is HD quality in an LED panel.
3. precisely seamless splicing
The splicing gap< 0.01mm.
4.Anti-slid handle design
Easy for transportation ,loading and uploading.
5. High strength Aluminum alloy material
The integral die-casting aluminum molding workmanship has provided with excellent flatness of the cabinet.
6. Front serviceable led screen for better experience
The front serviceable ultra HD LED Panel cabinet has fully described the strength of its light weight,met the needs of small space or where the needs of the cabinet thickness is needed, enhanced the vision of the space as well as its visionary effect. it allows for easy maintenance ,saving time and labor site.
7. Ultra wide viewing angle , different experience
Both 140 from horizontal and vertical for the viewing angle. Seeing from different directions,it would be still the natural and clear image in an LED panel.
Fine Pitch LED Panel Specification:
| Model | BHD-1.87 | BHD-2.5 |
| Pixel Pitch | 1.87mm | 2.5mm |
| Pixel Density | 284444pixels/m2 | 160000 pixels/m2 |
| LED Type | SMD2121 | SMD2121 |
| LED Configuration | 1R1G1B | 1R1G1B |
| Cabinet Dimension | 480*480mm | 480*480mm |
| Cabinet Resolution | 256*256px |
192*192px |
| Cabinet Weight | 8kg | 8kg |
| Cabinet Material | die casting aluminum | die casting aluminum |
| Ingress Protection(front/rear) | IP40/IP21 | IP40/IP21 |
| Brightness | >1200nits | >1200nits |
| Viewing Angle(H/V) | 140°/140° | 140°/140° |
| Driving Method | 1/22 Scan | 1/16 Scan |
| Frame Refresh | ≥ 60Hz | ≥ 60Hz |
| Data Refresh Rate | >1500Hz | >1500Hz |
| Gray Scale | 16bit | 16bit |
| Power Consumption(avg.) | 320w/m2 | 320w/m2 |
| Input Voltage | AC 110/220±10% 50~60Hz |
AC 110/220±10% 50~60Hz |
| Temperature (operating/storage) |
-20~50°C / -40~60°C | -20~50°C / -40~60°C |
| Humidity (operating/storage) |
10%~90%RH / 10%~85%RH | 10%~90%RH / 10%~85%RH |
| MTBF | ≥1000hrs | ≥1000hrs |
| Life Span | ≥50000hrs | ≥50000hrs |
| Pixel Failure | <0.0003 | <0.0003 |
Typical Applications:
Can be widely used in many different context, such as:Control Room, Reception Hall, Meeting Room, Command Center,Cinema,etc.
